Description: 2SD2394 D2394 2394 NPN Transistor 60V 3A Carbon Type 3 Pin Leads IC

2SD2394 D2394 2394 NPN Transistor 60V 3A Carbon Type 3 Pin Leads IC .2SD2394 is NPN Silicon Triple Diffused Planar Transistor.

Features:

1) Low VCE(sat).

2) Excellent electrical characteristics of DC current Gain hFE.

3) Wide SOA.

Pinouts

Absolute maximum ratings ( Ta=25°C )

1. Collector to Base Voltage: Vcbo = 80 V
2. Collector to Emitter Voltage: Vceo = 60 V
3. Emitter to Base Voltage: Vebo = 7 V
4. Collector Current: Ic = 3 A
5. Collector Dissipation : Pc = 2 W
6. Junction Temperature: Tj = 150°C
7. Storage Temperature: Tsg = -55 ~ +150°C

• 1. Collector to Base Voltage: Vcbo = 80 V

• 2. Collector to Emitter Voltage: Vceo = 60 V

• 3. Emitter to Base Voltage: Vebo = 7 V

• 4. Collector Current: Ic = 3 A

• 5. Collector Dissipation : Pc = 2 W

• 6. Junction Temperature: Tj = 150°C

• 7. Storage Temperature: Tsg = -55 ~ +150°C
