Picture of 3Pcs- 3296 202 Square Cermet 2K Ohm 1/2W Vertical Potentiometer Variable Resistors 3 Pin Leads 2K Ohm Trimpot Trimmer 202 Potentiometer 25 Turn 3 Pin Adjustment Trim Pot
Picture of 3Pcs- 3296 202 Square Cermet 2K Ohm 1/2W Vertical Potentiometer Variable Resistors 3 Pin Leads 2K Ohm Trimpot Trimmer 202 Potentiometer 25 Turn 3 Pin Adjustment Trim Pot

3Pcs- 3296 202 Square Cermet 2K Ohm 1/2W Vertical Potentiometer Variable Resistors 3 Pin Leads 2K Ohm Trimpot Trimmer 202 Potentiometer 25 Turn 3 Pin Adjustment Trim Pot

Category: Building Materials
SKU: UDBD04377
Seller: Udvabony BD
Visa/Mastercard 10% Discount(T&C)
Nagad 10% instant Cashback(T&C)
Tk 50
Tk 59
Tk 59
15% OFF
0 review(s)
  • Resistance: 2,000 Ohm
  • Tolerance: 10%
  • Power: 1/2 Watt
  • 25 Turn

Call For Order : 09613-800800

Description: 2K Ohm Potentiometer 202 Variable Resistor

This is a 2K ohm (202) 3296 series PCB Mounting Multi-turn trimpot. Multiturn potentiometers are used in application where accuracy and precision is important. As the name suggests the need to turn the know several times for going through the full scale of 0K ohm to 2KOhm. This 3296 series multi-turn variable resistor can also be easily mounted on breadboard.

Features:

  • Resistance: 2,000 Ohm
  • Tolerance: 10%
  • Power: 1/2 Watt
  • 25 Turn

Manufacturer Series3296
FamilyY
Resistance (Ohms)2000
Power Rating0.5 W
Tolerance (%)10
Product TypeTrimmer
Number of Turns25
Actuator TypeTop Slot
Termination StylePins
Shaft Diameter (mm)2.19
Resistive Element MaterialCermet
TechnologySealed
Operating Temperature-Min (Cel)-55
Operating Temperature-Max (Cel)150
MountingThrough Hole
TaperLinear
Width (mm)4.83
Height (mm)11.55
Length (mm)9.53
Temperature Coefficient (ppm/Cel)100
Actuator OrientationTop






  • Resistance: 2,000 Ohm
  • Tolerance: 10%
  • Power: 1/2 Watt
  • 25 Turn
