Description: 0.22uF 275VAC Axial Film Molded Capacitor

Features:

• 1.Boxtypeprovidestheidenticalouterappearance.
• 2.Withstandingovervoltagestressing.
• 3.Excellentactiveandpassiveflameresistantabilities.
• 4.Withstanding2.5KVimpulsevoltage,ClassX2.

Specifications:

• Design (resistance / capacitor): Radial
• Capacity (electrical): 0.22 μF
• Tolerance (plus / minus): 10%
• Type (manufacturer): MKP-X2
• Rated voltage: 275 V / AC
• Connections (Components): Soldering pins
• External Length: 26.5 mm
• Raster (pitch): 22.5 mm
• RoHS Compliant: Yes
• Varistor type (category): Suppressor capacitor MKP-X2
• External Height: 15 mm
• External Width: 6 mm
• Box type provides the identical outer appearance.
• With standing over voltage stressing.
• Excellent active and passive flame resistant abilities.
• With standing 2.5KV impulse voltage,ClassX2.

Typicalapplications:

• • 1.Asanacross-the-linetypenoisesuppressioncapacitor,andsuitable
  • 2. Grid power supply of electronic instruments and electronic equipment, switch, contacts produces a spark discharge sites
  • 3.Electrictools,lighting,hairdryers,waterheatersandotherhouseholdelectricalappliances

• Design (resistance / capacitor): Radial
• Capacity (electrical): 0.22 μF
• Tolerance (plus / minus): 10%
• Type (manufacturer): MKP-X2
• Rated voltage: 275 V / AC
• Connections (Components): Soldering pins
• External Length: 26.5 mm
• Raster (pitch): 22.5 mm
• RoHS Compliant: Yes
• Varistor type (category): Suppressor capacitor MKP-X2
• External Height: 15 mm
• External Width: 6 mm
• Box type provides the identical outer appearance.
• With standing over voltage stressing.
• Excellent active and passive flame resistant abilities.
• With standing 2.5KV impulse voltage,ClassX2.
