Description: Metallized Polypropylene Film 474j Capacitor 470nF 400V Mylar Polyester Film

Applies to pulse circuits, widely used in a variety of electrical equipment, electrical and electronic filtering, blocking, bypass, coupling, and noise reduction and other occasions.

Specification:

Product Name : Metallized Polyester Film Capacitor;

Rated Voltage : 400V;

Operating Temperature: -40°C ~ +85°C

Capacitance : 470nF

Capacitance Tolerance : +/-5%

Lead Spacing : 15mm/0.6″

Lead Diameter : 0.7mm/0.03″;

Weight : 18g;

Features:

Dissipation Factor is normally low and stable against high frequency and change of temperature.

High reliable because of its excellent Self-Healing performance.

Small inherent temperature rise and small size

Epoxy resin powder coating or Epoxy DIP coating

Application:

Recommended for high-frequency circuits like S-curve compensating circuit.

Widely used in high frequency, DC, AC and pulse circuits.

• Product Name : Metallized Polyester Film Capacitor;
• Rated Voltage : 400V;
• Operating Temperature: -40°C ~ +85°C
• Capacitance : 470nF
• Capacitance Tolerance : +/-5%
• ;Lead Spacing : 15mm/0.6″
• Lead Diameter : 0.7mm/0.03″;
