Voltage measurement range: 0.0V-100V

Current test range: 0-999mA, 0-10A, 0-50A, 0-100A

Power supply range: DC4-30.0V

Voltage error: ±0.1%

Current error: ±1%

External shunt specifications: 75 milliohms

• Working current< 20mA

Refresh rate: About 300mS once

Display method: Double three 0.28" LED digital tube

Display color: Red + Blue

Lead length: 15cm

Dimensions: 48 x 29 x 22 mm

Mounting holes: 46 x 27 mm

Operating temperature: -10°C~65°C

Voltage measurement range: 0.0V-100V

Current test range: 0-999mA, 0-10A, 0-50A, 0-100A

Power supply range: DC4-30.0V

Voltage error: &plusmn;0.1%

Current error: &plusmn;1%

External shunt specifications: 75 milliohms

• Working current&lt; 20mA

Refresh rate: About 300mS once

Display method: Double three 0.28&quot; LED digital tube

Display color: Red + Blue

Lead length: 15cm

Dimensions: 48 x 29 x 22 mm

Mounting holes: 46 x 27 mm

Operating temperature: -10&deg;C~65&deg;C
