Hall Effect Sensor Module A3144E 49E 4 Pin Hall Sensor LM393 Hall Effect Detection Magnetic Switches Speed Counting Sensor Module For Arduino

Category: Building Materials
SKU: UDBD03905
Seller: Udvabony BD
Visa/Mastercard 10% Discount(T&C)
Nagad 10% instant Cashback(T&C)
Tk 84
Tk 99
Tk 99
15% OFF
  • S49E hall sensor
  • Features wide range voltage comparator LM393
  • Adjustable sensitivity (potentiometer)
  • Signal output indicator
  • Analog / Digital output
  • Small size, 32x14mm
  • Mounting screw hole of 3mm
  • You can use a DC power supply 3-5.5v
  • Real-time output signal of the Hall
  • After the adoption of the comparator output signal more stable finishing
  • The comparator output capability 16mA
  • Power indicator
  • The comparator output indicator light
  • Control distance is measured: less 1CM

Call For Order : 09613-800800



Description: Hall Effect Sensor Module A3144E 49E 4 Pin Hall Sensor LM393 Linear Hall Effect Sensitivity Detection

This module can be used to detect the presence of an magnetic field. If there is an magnetic field present, it will report a high level signal. It can be used in many applications such as RPM sensor (for counting the number of shaft revolutions), Robot speed and distance measurements, door switch and robot arm position sensor. Generally, it can be used for any magnetic field detection.

This Hall Sensor Module used Hall Sensor A3144E. The Hall Sensor measures the Hall Effect, which is a production of a voltage difference across an electrical conductor, transverse to an electric current in the conductor as well as a magnetic field perpendicular to the current. The output of the Hall sensor switches low and turns on when a magnetic field perpendicular to the Hall sensor exceeds the BOP threshold, and it switches high and turn on when the magnetic field disappears. And the comparator circuit that make the output signal more reliability.

Features:

  • S49E hall sensor
  • Features wide range voltage comparator LM393
  • Adjustable sensitivity (potentiometer)
  • Signal output indicator
  • Analog / Digital output
  • Small size, 32x14mm
  • Mounting screw hole of 3mm
  • You can use a DC power supply 3-5.5v
  • Real-time output signal of the Hall
  • After the adoption of the comparator output signal more stable finishing
  • The comparator output capability 16mA
  • Power indicator
  • The comparator output indicator light
  • Control distance is measured: less 1CM

Specifications:

  • Volt: 2.3V ~ 5.3V
  • Dimension: 27.0mm * 15.5mm
  • Mounting holes size: 2.0mm

Applications:

  • Motor shaft speed measurement (shaftencoder)
  • Object position detection

How to Use:

In the case of working with Arduino / microntroller /Raspberry:

  • VCC ↔ 2.3V ~ 5.3V
  • GND ↔ power supply ground
  • AOUT (analog sensor output)↔ Arduino/ MCU input
  • DOUT (digital sensor output)↔ Arduino/MCU input

Package included:

  • 1 x Hall Effect Sensor Module A3144E 49E 4 Pin Hall Sensor LM393 Linear Hall Effect Sensitivity Detection Magnetic Switch Speed Counting Sensor Module For Arduino






  • S49E hall sensor
  • Features wide range voltage comparator LM393
  • Adjustable sensitivity (potentiometer)
  • Signal output indicator
  • Analog / Digital output
  • Small size, 32x14mm
  • Mounting screw hole of 3mm
  • You can use a DC power supply 3-5.5v
  • Real-time output signal of the Hall
  • After the adoption of the comparator output signal more stable finishing
  • The comparator output capability 16mA
  • Power indicator
  • The comparator output indicator light
  • Control distance is measured: less 1CM
Customer Questions and answers :
