Picture of Hi-Fi PAM8610 Audio Stereo Amplifier Board Module Dual D Class Channel 2x10W 12V Mini Stereo Digital Audio Amplifier Circuit
Picture of Hi-Fi PAM8610 Audio Stereo Amplifier Board Module Dual D Class Channel 2x10W 12V Mini Stereo Digital Audio Amplifier Circuit

Hi-Fi PAM8610 Audio Stereo Amplifier Board Module Dual D Class Channel 2x10W 12V Mini Stereo Digital Audio Amplifier Circuit

Category: Electrical Accessories
SKU: GRIC821019
Seller: GREEN ELECTRONICS.
Tk 288
0 review(s)
  • Work: Class D (PWM modulation)
  • Chip selection: PAM8610
  • Scope of supply: DC6 ~ 15V
  • Keep pushing Voltage: DC12V
  • Output Power: 10W * 2
  • Channel Type: Dual Channel
  • SNR: 90dB
  • Frequency response: 20Hz-15KHz
  • Quiescent current: 20MA(DC 12V)
  • Input Impedance: 20M
  • Harmonic distortion: <0.1 percentage
  • Rated output power: 10w+10w (8Ω)
  • Board size: length 40mmX width 40mmX height 19m

Call For Order : 09613-800800
  • Work: Class D (PWM modulation)
  • Chip selection: PAM8610
  • Scope of supply: DC6 ~ 15V
  • Keep pushing Voltage: DC12V
  • Output Power: 10W * 2
  • Channel Type: Dual Channel
  • SNR: 90dB
  • Frequency response: 20Hz-15KHz
  • Quiescent current: 20MA(DC 12V)
  • Input Impedance: 20M
  • Harmonic distortion: <0.1 percentage
  • Rated output power: 10w+10w (8Ω)
  • Board size: length 40mmX width 40mmX height 19m





  • Work: Class D (PWM modulation)
  • Chip selection: PAM8610
  • Scope of supply: DC6 ~ 15V
  • Keep pushing Voltage: DC12V
  • Output Power: 10W * 2
  • Channel Type: Dual Channel
  • SNR: 90dB
  • Frequency response: 20Hz-15KHz
  • Quiescent current: 20MA(DC 12V)
  • Input Impedance: 20M
  • Harmonic distortion: <0.1 percentage
  • Rated output power: 10w+10w (8Ω)
  • Board size: length 40mmX width 40mmX height 19m
