Full Specification

Item

Motherboard

Brand

Gigabyte

Motherboard Type

Standard

Chipset

Intel B85 Express Chipset

Supported Processors

Support for Intel Core i7 / Core i5 / Core i3 / Intel Pentium / Intel Celeron processors in the LGA1150 Package L3 Cache Varies with CPU

Max Memory

4 x DDR3 DIMM Sockets Supporting up to 32 GB of System Memory

Onboard Video

1 x D-Sub Port

1 x HDMI Port

1 x DVI-D Port

Onboard Audio

Realtek ALC892 Codec

High Definition Audio

2/4/5.1/7.1-Channel Support for S/PDIF In/Out

Onboard LAN

Realtek GbE LAN chip (10/100/1000 Mbit)

Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12 V power connector

4 x SATA III 6 Gb/s connectors

2 x SATA II 3 Gb/s connectors

1 x CPU fan header

1 x system fan header

1 x front panel header

1 x front panel audio header

1 x USB 3.0/2.0 header

2 x USB 2.0/1.1 headers

1 x serial port header

1 x parallel port header

1 x Clear CMOS jumper

Other Features

1 x PS/2 keyboard/mouse port

2 x USB 3.0/2.0 ports

4 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks
