Overview:

• Simultaneous 2.4GHz 300Mbps and 5GHz 300Mbps connections for 600Mbps of total available bandwidth
• 2*USB Ports - Easily share a printer locally and files & media with networked devices or remotely via FTP server
• Full gigabit ports ensure ultimate transfer speeds
• Achieves blazing WAN to LAN throughput of over 800Mbps with hardware NAT
• Guest Network Access provides secure Wi-Fi access for guests sharing your home or office network

Specifications:

HARDWARE FEATURES
Interface    4 10/100/1000Mbps LAN Ports
1 10/100/1000Mbps WAN Port
2 USB 2.0 Ports
Button    WPS/Reset Button
Wireless On/Off Switch
Power On/Off Button
Dimensions (W X D X H)    9.6x6.4x1.3 in.(243x160.6x32.5mm)
Antenna    2 external detachable dual band antennas (RP-SMA)
External Power Supply    12VDC / 1.5A
WIRELESS FEATURES
Wireless Standards    IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency    2.4GHz & 5GHz
Signal Rate    5GHz: Up to 300Mbps
2.4GHz: Up to 300Mbps
Reception Sensitivity    270M_2.4G: -70dBm
195M_2.4G: -71dBm
130M_2.4G: -74dBm
54M_2.4G: -79dBm
6M_2.4G: -94dBm
270M_5G: -67dBm
195M_5G: -70dBm
130M_5G: -73dBm
54M_5G: -79dBm
6M_5G: -92dBm
Transmit Power    CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
FCC:
<30dBm
Wireless Functions    Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security    64/128-bit WEP,WPA / WPA2,WPA-PSK/ WPA2-PSK encryption
Guest Network    2.4GHz guest network × 1
5GHz guest network × 1
SOFTWARE FEATURES
Quality of Service    WMM, Bandwidth Control
WAN Type    Dynamic IP/Static IP/PPPoE/
PPTP (Dual Access)/L2TP (Dual Access)/BigPond
Management    Access Control
Local Management
Remote Management
DHCP    Server, Client, DHCP Client List,
Address Reservation
Port Forwarding    Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS    DynDns, Comexe, NO-IP
VPN Pass-Through    PPTP, L2TP, IPSec
Access Control    Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security    DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
USB Sharing    Support Samba(Storage)/FTP Server/Media Server/Printer Server
OTHERS
Certification    CE, FCC, IC, RoHS
Package Contents    TL-WDR3600
2 detachable dual band antennas
Power supply unit
Resource CD
Ethernet Cable
Quick Installation Guide
System Requirements    Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows8/ 8.1/10
MAC® OS, NetWare®, UNIX® or Linux
Environment    Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Warranty:

One year warranty
