Description: PWM Stepper Motor Driver Controller 12V-24V

PWM Stepper Motor Driver Controller 12V-24V Stepper Motor Pulse Pwm Signal Generate Module Motor Speed Frequency Direction Control

Feature：

• This module is a pulse generation module, supply the control signal to stepper driver. To control the stepper motor, it must be equipped with a drive.
• This simple controller + stepper motor + stepper motor + DC power supply can be composed of a simple set of control platform.
• The controller has high 5.4k-160khz, middle 540-16.6khz, low 80-2.4khz total of 3 kinds of low frequency signal can be used to select the jumper.
• Can produce pulse signal, can also produce PWM signal, can choose the jumper.
• The frequency of measurement: PUL and common cathode end.

Different stepper driver may mark different name EN=ENA=FREE Enable PUL=PULS=CLK Pulse DIR=CW=CWW Direction

Common anode Connection method (B) EN+ PUL+ DIR+ connect together to com+. EN- connect EN PUL- connect CLK DIR- connect DIR
