Description: DC 12V 5A Songle Relay 8 Pin DPDT P C B Mount

Songle Relay 8 Leg Two open Two closed 12VDC 5A250VDC.

Features:

• Rated voltage: 12 V
• Resistance of coil: 46 270 1050
• Rated current: 108 45 22.5
• Maximum operating voltage: 4 9.6 19.2
• The minimum output voltage (in DC): 0.25 0.6 1.2
• Coil Resistance (Ω ± 10%): 35,200,800
• Rated current (mA): 144 60 30
• Maximum operating voltage (V DC): 4 9.6 19.2
• The minimum output voltage (in DC): 0.25 0.2 1.2
• Maximum overload voltage:
• 23 of the rated voltage, 130% of the rated voltage at 70 degrees Celsius, 170%
• Insulation resistance: 100m min 500vdc 500V DC
• Dielectric strength between open contacts: 1000vac (for one minute)
• Between the contacts and the coil: 5000vac (per minute)
• Operating time: 20 ms
• Release time: 10 ms
• Temperature range: -40 ℃ to + 70 ℃
• Operational extremes: 10 g 11 ms
• Limits of damage: 100 g 6 ms
• Resistance to vibration: 10-55 Hz, 1.5 mm
• Max. frequency switching
• Mechanical: 18,000 operations / hr
• Electrical: 1,800 operations / hr
• Humidity: 40-85%
• Weight: approx. 14 g
• Safety standard: tuv cqc

• Rated voltage: 12 V
• Resistance of coil: 46 270 1050
• Rated current: 108 45 22.5
• Maximum operating voltage: 4 9.6 19.2
• The minimum output voltage (in DC): 0.25 0.6 1.2
• Coil Resistance (Ω ± 10%): 35,200,800
• Rated current: 5A
