Generator

COUNTRY OF ASSEMBLY

China

BRAND

SONALI

MODEL

SPL8600R

COUNTRY OF ORIGIN

China

RATED OUTPUT

7.0 KW

MAX. OUTPUT

7.5 KW

RATED AMPERE

32 A

DC OUTPUT

12V / 18A

RECEPTACLE

EU Socket 50A

Engine

ENGINE MODEL

192FD

ENGINE TYPE

Air Cooled 4-Strokes

DISPLACEMENT

460cc

SPEED

3000 rpm

MAXIMUM ENGINE POWER

12kw/16hp

FUEL TANK CAPACITY

25 Ltr

FUEL CONSUMPTION (100% Load)

3Ltr/Hr

CONTINUOUS OPERATION HOUR

8.3 Hrs

ENGINE OIL CAPACITY

1.2 Ltr

OIL ALERT SYSTEM

Standard

STARTING SYSTEM

Recoil

NOISE LEVEL@7M

72 dBA

Alternator

Brand

SENCI

Model

SC190-158

Carbopn Type

TFD

Power Factor

1 Cos

No of Phase

Single Phase

AC Voltage

220V

Voltage System

AVR

Frequency

50Hz

Insulation Class

F

Made with

100% Copper

Dimension & Weight

DIMENSION LxWxH (MM)

725x550x610

NET WEIGHT

94kg
