Overview:

• EAP Controller Software enables administrators to easily manage hundreds of EAPs*
• Support Power over Ethernet（802.3af）for convenient and affordable installation
• Simple mounting design to easily mount to a wall or ceiling
• Captive portal provides one convenient method of authentication for WiFi guests
• WPA/WPA2-enterprise, 802.1X with RADIUS secure authentication and rogue access point detection ensure the security of WLAN
• Gigabit Ethernet port enables bandwidth-intensive application or multimedia transferring

Specifications:

HARDWARE FEATURES
Interface    Gigabit Ethernet (RJ-45) Port *1（Support IEEE802.3af PoE）
Console Port *1
Button    Reset, Power On/Off
Power Supply    PoE or External 12VDC / 1A Power Supply
Dimensions (W X D X H)    7.1 x 7.1 x 1.9 in. (180*180*47.5mm)
Power Consumption    4.4 W
Antenna Type    Internal 2* 4dBi Omni
Mounting    Ceiling /Wall Mounting (Kits included)
Physical Security Lock    Kensington Lock Slot
Watch Dog    Yes
WIRELESS FEATURES
Wireless Standards    IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency    2.4-2.4835GHz
Signal Rate    11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity    300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER
Transmit Power    CE:
<20dBm
FCC:
<26dBm
Wireless Functions    Multiple SSIDs （Up to 8 SSIDs）
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control （Adjust Transmit Power on dBm）
QoS(WMM)
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security    Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
MANAGEMENT
EAP Controller Software    Yes
Cluster    Up to 24 APs in one cluster
Email Alerts    Yes
LED ON/OFF Control    Yes
Management MAC Access Control    Yes
SNMP    v1,v2c
System Logging    Local/Remote Syslog    Local/Remote Syslog
Telnet    Yes
Web-based Management    HTTP/HTTPS
CLI (Command Line Interface)    Yes
OTHERS
Certification    CE, FCC, RoHS
Package Contents    300Mbps Wireless N Gigabit Ceiling Mount Access Point EAP120
Power Adapter
Mounting Kits
Resource CD
Installation Guide
System Requirements    Microsoft Windows XP, Vista, Windows 7, Windows 8
Environment    Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Warranty:

One year warranty
