Description: Weight Measurement Circuit  XA-VVV03-01 Weight Circuit for Digital Scale

The XA-VVV03-01 Weight Measurement Circuit is a compact, high-precision signal conditioning module designed for digital weighing machines and electronic scales. Built for reliability and accurate sensor data conversion, this compatible circuit seamlessly integrates with load cells to deliver fast and stable weight readings.

Ideal for DIY scale projects, industrial weighing systems, and embedded electronics, the XA-VVV03-01 supports single-point load cells and offers amplified, filtered signal output. Whether you’re building a custom scale or replacing a faulty circuit, this module provides the accuracy and consistency required for modern weight measurement systems.

 Specifications:

• Model: XA-VVV03-01
• Product Type: Weight Measurement Signal Amplifier Circuit
• Sensor Compatibility: Load cells (single-point or strain gauge type)
• Output Type: Analog/Digital (depending on configuration)
• Material: High-quality PCB board
• Interface Type: Pin headers or terminal block
• Signal Stability: High filtering for noise reduction
• Dimensions: Compact, board size ~66mm x 31mm
• Usage: Internal use in digital weighing machines
• Operating Temperature: 0°C to 50°C

Features:

•  High-Precision Signal Conversion – Accurate weight data from load cells
•  Stable 5V Operation – Works with standard microcontrollers and power sources
•  Noise-Filtered Output – Clean signal for more stable and accurate measurements
•  Compact Design – Ideal for small enclosures and portable scale builds
•  Plug-and-Play Integration – Easy to connect with load cells and controllers
• Durable PCB – Built with industrial-grade materials for long-term use

Applications:

•  Digital Weight Machines
•  Lab & Industrial Scales
•  DIY Electronic Scale Projects
•  Postal and Parcel Weighing Systems
• Solar-powered Smart Scales

• Model: XA-VVV03-01
• Product Type: Weight Measurement Signal Amplifier Circuit
• Sensor Compatibility: Load cells (single-point or strain gauge type)
• Output Type: Analog/Digital (depending on configuration)
• Material: High-quality PCB board
• Interface Type: Pin headers or terminal block
• Signal Stability: High filtering for noise reduction
• Dimensions: Compact, board size ~66mm x 31mm
• Usage: Internal use in digital weighing machines
• Operating Temperature: 0°C to 50°C
